Throttle side EPA function, or ATL function setting also affects neutral brake side operation.
The Idle-up 2.3.11 Idle up or Engine Cut 2.5.9 Engine cut function has priority.
2.3.5 Channel reverse
This function reverses the direction of operation of the servos related to the transmitter's
steering, throttle, channel 3, 4, 5, 6, 7, and 8 operations.
CH1 to CH8 are default set as R.
Setting steps: turn on the RC8X, into home page,
click the button at the left bottom of RC8X into
System menu, click into Basic menu, click the blue
select box named Channel reverse can into the menu to
set the CH1 to CH8 normal or reverse.
Back: click the button or short press the power
button to return to the previous menu.
Attention: “R” indicates REVERSE, “N” indicates Normal.
If the channel has selected reverse, check the control of the corresponding channel on the
model to confirm whether the response direction of the device connected to the channel is
correct or not.
Attention: After the receiver is connected to the ESC, please calibrate the ESC and the
transmitter according to the ESC manual, and then operate the throttle trigger, if there is no
response, please set Channel 3 from “N” to “R” and then operate the throttle trigger to
check whether the throttle channel device responds.
