A.B.S trigger to start: Sets the trigger point that the A.B.S function is performed. The initial
value is 30, 5 to 95 can be selected.
Tigger mode: Normal and Reverse can be selected. “Normal” indicates the neutral to
trigger point is the range of motion. “Reverse” indicates the range from the trigger point to
the full brake side is the operating range.
Attention:
A.B.S can be independently set for the brakes which are controlled by the Brake 2 and Brake
3 (brake 2 and 3 are auxiliary channels). Brake mixing can be set under the mixing menu.
Brake 1, 2, 3 can be adjusted independently except the trigger point of the setting item.
Setting steps: turn on the RC8X, into home page, click the button at the left bottom of
RC8X into System menu, click into Racing curve menu, click the blue select box named
A.B.S. into the menu to set it. Click “-“ to decrease the value and click “+” to increase the
value.
Reset: click Reset will make the value back to the default number.
Back: click the button or short press the power button to return to the previous menu.
2.5.8 Start
If the track is slippery and you begin to accelerate by
pushing the trigger to full throttle, the car wheels will spin
and will not accelerate smoothly. When the Start function
is activated, merely operating the throttle trigger slowly
causes the throttle servo to automatically switch from the
