RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
63
gear ratio, click “-“ can decrease the value, and click “+” can increase the value, 50 to 130
can be selected.
Setting steps: turn on the RC8X, into home page, click the button at the left bottom of
RC8X into System menu, click into Tools menu, click the blue select box named Gear ratio
chart to set the parameters for pan cars. Click “-“ can decrease the value and click “+” can
increase the value.
Back: click the button or short press the power button to return to the previous menu.
2.3 Basic menu
2.3.1 Receiver select
Enter steps: turn on the RC8X, into home page, click the button at the left bottom of
RC8X into System menu, click into Tools menu,
click the blue select box named Receiver select to
select the receiver and set the Child ID mode function.
RC8X is default packed with the receiver R8FG and
has bind success already.
Every transmitter has a unique ID code. Before
using, binding transmitter to receiver is a must. When
binding is finished, ID code will be stored in the
receiver, no need to rebind unless the receiver is going
to work with another transmitter. If you purchase a new
compatible receiver, binding needs to be done before

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
