RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
94
Reset: click Reset will make the value back to the default number.
Back: click the button or short press the power button to return to the previous menu.
2.5.5 Throttle speed
Sudden throttle trigger operation on a slippery road will cause the wheels to spin and the
vehicle cannot accelerate smoothly. Setting the throttle speed function reduces wasteful battery
consumption while at the same time permitting a smooth, enjoyable operation.

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
