RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
95
Attention:
Throttle servo (ESC) operation is delayed so that the drive wheels will not spin even if the throttle
trigger is operated more than necessary. This delay function is not performed when the throttle
trigger is returned and at brake operation.
Mode：All point, High-Low point, Three-point can be selected.
All point mode High-Low point mode Three-point mode
All point：A delay is set over the entire throttle range.
Turn: the initial value is 100, 1 to 100 can be selected, if the value is 100, it means there is no
delay.
Servo operation is delayed.
Return: the initial value is 100, 1 to 100 can be selected, if the value is 100, it means there is no
delay.
Servo operation is delayed.

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
