RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
96
High-Low point：A delay can be set in 2 ranges with Point 1 as the boundary.
Turn："Low" and "High" turn direction delay adjustment, the initial value of High or Low turn
speed is 100, 1 to 100 can be selected, if the value is 100, it means there is no delay.
Servo operation is delayed.
Return： "Low" and "High" return direction delay adjustment, the initial value of High or Low
return speed is 100, 1 to 100 can be selected, if the value is 100, it means there is no delay.
Servo operation is delayed.
Point1: is for speed switching point adjustment. The initial value is 30, 0 to 100 can be selected to
change the "Low" and "High" switching point.
Three points: A delay can be set in 3 ranges with Point 1 and Point 2 as the boundaries.
Turn: "Low", "Middle", or "High" turn direction delay adjustment.
The initial value is 100, 1 to 100 can be selected, if the value is 100, it means there is no delay.
Servo operation is delayed.
Return：
"Low", "Middle", or "High" return direction delay adjustment.
The initial value is 100, 1 to 100 can be selected, if the value is 100, it means there is no delay.

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
