RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
97
Servo operation is delayed.
Point1/Point2: is for speed switching point adjustment. The initial value of Point1 is 30 and the
initial value of Point2 is 60, 0 to 100 can be selected to change the "Low", “Middle”, and "High"
switching point.
The throttle speed "Turn" and "Return" adjustment can be controlled with digital trim DT1 to DT4
or digital dial DL1 etc. with the Trim/Dial select function in Tools menu.
Attention:
Setting the speed function in the return direction slows the deceleration of the car body, so
please be careful to set it carefully.
Setting steps: turn on the RC8X, into home page, click the button at the left bottom of
RC8X into System menu, click into Racing curve menu, click the blue select box named
Throttle speed into the menu to set the throttle speed. Click “-“ to decrease the value and click
“+” to increase the value.
Reset: click Reset will make the value back to the default number.
Back: click the button or short press the power button to return to the previous menu.

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
