corresponding switch, so each transmitter is slightly different, please ignore it.
2.2 Tools menu
2.2.1 Trim/Dial select
Trim/Dial function select: This function is used to assign functions for the transmitter’s
digital trimmer button DT1, DT2, DT3, DT4, and dial button DL1. Click 1/2 at the top right corner
to switch the setting menu.
Button: DT1/DT2/DT3/DT4: the four digital trimmer buttons on the left side of the wheel.
DL1: the dial button is on the front right of the transmitter. For details of all the buttons,
please refer to 1.2.5 Buttons Introduction.
Dir.: the direction for the four digital trimmer buttons and the dial button, normal and
reverse can be selected. If you select Nor., the value will increase when press clockwise the digital
trimmer button DT1, DT2, DT3, DT4 or rotate clockwise the dial button DL1. If you select Rev., the
value will decrease when pressing anticlockwise the digital trimmer button DT1, DT2, DT3, DT4 or
rotate anticlockwise the dial button DL1.
Step: indicates the interval of the number change every time the button is pressed. For
example, set the Step value to 6, and then each time the DT1 button is pressed, the value will
increase or decrease by 6. The value of Step is defaults 2.
Function: DT1/DT2/DT3/DT4/DL1 can be set to control one of the functions as below:
Steering trim, throttle trim, rotary knob trim, flap, dual rate, sub trim channel1/2/3/4/5/6/7/8,
acceleration forward/brake1/ brake2/ brake3, steering curve, throttle curve, steering speed
turn/return, throttle speed turn(high/middle/low), throttle speed return(high/middle/low),
