RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
64
using it. The binding steps can refer to 1.3.2 Binding
Receiver select: Except for the receiver R8FG, RC8X is also compatible with the receivers R7FG,
R6FG, R6F, R4FGM, R4F, R8F, R8EF, R8FM, R8SM, R8XM.
Attention: The receivers that compatible with the RC8X is keep updating, please pay
attention to RadioLink official website www.radiolink.com to get the latest firmware to check the
newly launched receiver.
If you are ready to change the receiver, only to bind the RC8X to the receiver you want to use
is needed, any setting in this menu is not needed. This page is only used to display the receiver
models which compatible with the RC8X.
2.3.2 Child ID mode
Child ID mode function means designating a
subsidiary ID among multiple binding receivers to
realize the control. RC8X is capable of an arbitrary ID
designation among a maximum of 16 binding receivers,
making long-distance rescue of RC cars or boats
achievable.
For example, RC8X has completed the binding with
16 different boats and the setup of respective
parameters. Turn on the Child ID mode function, select
ID_0 boat and drive it to the central of water but it
stops working because low battery voltage. Then we

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
