servo movement. Click “-“ can decrease the value, and click “+” can increase the value. The
initial value is 120%, 0% to 120% can be selected.
Reset: click Reset will make the value back to the default number.
Back: click the button or short press the power button to return to the previous menu.
2.3.14 Channel setting
Channel 1 to channel 8 can be customized. All the eight channels can be set controlled by
Steering, Throttle, Rotary knob, DT1, DT2, DT3, DT4, DL1, PS1, PS2, PS3, PS4, PS5, Steering switch,
Trigger switch.
Channel 1: It default to control the steering wheel. Steering, Throttle, Rotary knob, DT1, DT2,
DT3, DT4, DL1, PS1, PS2, PS3, PS4, PS5, Steering switch, Trigger switch can be set to control the
channel1.
Channel 2: It default to control the throttle trigger. Steering, Throttle, Rotary knob, DT1, DT2,
DT3, DT4, DL1, PS1, PS2, PS3, PS4, PS5, Steering switch, Trigger switch can be set to control the
channel2.
Channel 3: It default to control by the Rotary knob. Steering, Throttle, Rotary knob, DT1, DT2,
DT3, DT4, DL1, PS1, PS2, PS3, PS4, PS5, Steering switch, Trigger switch can be set to control the
channel1.
Channel 4: it defaults controlled by PS1, the same setting as channel 3.
Channel 5: it defaults controlled by PS5, the same setting as channel 3.
Channel 6: it defaults controlled by PS2, the same setting as channel 3.
Channel 7: it defaults controlled by PS4, the same setting as channel 3.
