RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
125
120% can be selected.
Right: for right, brake or down side mixing amount adjustment. The initial value is 50%,
-120% to 120% can be selected.
Program. Mixing1 2/2
Click 1/2 at the top right corner to switch the first programmable mixing setting page to the
second programmable mixing setting page.
Switch select:
PS1/PS2/PS3/PS4/PS5/Steering/Trigger can be selected
to turn on or turn off the programmable mixing
function, select “NULL” indicate that this function is
not enabled.
Mixing: The button at the right of “Mixing” is OFF,
and the background color of the select box is grey,
indicating that the Program. mixing1 function is turn off.
The button at the right of “Mixing” is ON, and the
background color of the select box is blue, indicating
that the Program. mixing1 function is turn on.
MIX mode: The button at the right of “MIX mode” is OFF, and the background color of the
select box is grey, indicating that the EXP function of the channel2 and other settings are not
mixed. The button at the right of “MIX mode” is ON, and the background color of the select
box is blue, indicating that the EXP function of the channel2 and other settings are mixed.

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
