RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
124
EXP curve:
Quick/Slow: is for the rate of EXP/VTR/Multiple point curve.
0% to 100% indicates the quick EXP/VTR/Multiple point rate, and -1% to -100 indicates the
slow EXP/VTR/Multiple point rate. The vertical cursor line moves in conjunction with the changes
of the curve rate value.
Offset: The master channel mixing center point (the point that the direction changes) can be
offset.
EXP/VTR/Multiple point curve rate: The initial value is 0%, -100% to 100% can be selected.
Fine tune(L)/(R): To set the right and left steering curves separately. The initial value is 0%,
-200% to +200% can be selected.
EXP curve, VTR curve, Multiple point curve mixing can be set from master channel to slave
channel. For details on how to set each curve, please refer to: 2.5.1 Steering curve and 2.5.2
Throttle curve.
Mixing rate:
Left: for left, forward or upside mixing amount adjustment. The initial value is 50%, -120% to

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
