RadioLink Electronic Limited
www.radiolink.com
ESC1 rate/ESC2 rate: Adjust the front and rear motor controller operation amount by click
“+” and “-“, by pressing the button “+” to adjust the rate of ESC2 and by pressing the
button “-“ to adjust the rate of ESC1 when both the value of ESC1 and ESC2 are 100% (the
initial value). Only one of the ESC rates can lower than 100%, for example, if the ESC1 rate is 90%
and the ESC2 rate is 100%, you press the button “+” will make the rate of ESC1 increase to
100% first and then decrease the rate of ESC2.
Dual ESC mixing 2/2
Click 1/2 at the top right corner to switch the
setting menu from Dual ESC mixing mode, rate, channel
setting menu to the 2/2 Dual ESC mixing switch select
menu.
Dual ESC switch: DT1/DT2/DT3/DT4/DL1 can be set
to switch the Dual ESC (front) and the Dual ESC (rear),
select “NULL” indicate that this function is not enabled.
Drive rate: the same function as ESC1 rate/ESC2 rate in the Dual ESC mixing 1/2 menu.
DT1/DT2/DT3/DT4/DL1 can be set to adjust the Dual ESC ratio, select “NULL” indicate that this
function is not enabled.
Dual ESC (front)/Dual ESC (4WD)/Dual ESC (rear): PS1/PS2/PS3/PS4/PS5/Steering/Trigger
can be selected to trigger one of the Dual ESC types, select “NULL” indicate that this function is
not enabled.
As this function drives 2 separate motors simultaneously, a mutual load will be applied. Use
To Next Page
