to trigger one of the Dual ESC types.
Trigger ratio is suggested to set as Forward 50: Brake 50.
Dual ESC mixing 1/2
Mixing: The button at the right of “Mixing” is OFF,
and the background color of the select box is grey,
indicating that the Dual ESC mixing function is turn off. The
button at the right of “Mixing” is ON, and the
background color of the select box is blue, indicating that
the Dual ESC mixing function is turn on.
MIX mode: The button at the right of “MIX mode” is
OFF, and the background color of the select box is grey,
indicating that the EXP function of the channel2 and other
settings are not mixed. The button at the right of “MIX
mode” is ON, and the background color of the select box is blue, indicating that the EXP
function of the channel2 and other settings are mixed.
Trim mode: The button at the right of “Trim mode” is OFF, and the background color of the
select box is grey, indicating that the trim of the channel2 is not mixed. The button at the right of
“Trim mode” is ON, and the background color of the select box is blue, indicating that the trim
of the channel2 is mixed.
ESC1 channel/ESC2 channel: set the controlled channel for ESC1/ESC2, channel1 to channel
8 can be selected.

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
