RadioLink Electronic Limited
www.radiolink.com
The steering left and right servo travels are adjusted simultaneously. This setting is linked to
transmitter grip trim DT3. When DT3 is assigned another function, dual-rate can be adjusted with
this menu.
ATL indicates the brake rate.
This function decreases the set value when the
braking effect is strong and increases the set value
when the braking effect is weak. This function is
linked to transmitter grip trim DT4. When DT4 is
assigned another function, this function can be set
with this menu.
Setting steps: turn on the RC8X, into home page,
click the button at the left bottom of RC8X into
System menu, click into Basic menu, click the
blue select box named D/R, ATL can into the menu to
set steering rate and brake rate. Click “-“ can decrease the value, and click “+” can increase
the value.
Reset: click Reset will make the value back to the default number.
Back: click the button or short press the power button to return to the previous menu.
Steering rate: The initial value of steering rate is 100%, 0% to 100% can be selected. Click
“-“ , “+” or push the trimer button DT3 can adjust the steering effect.
Steering Rate Switch select: The initial switch of steering rate is DT3, DT1/DT2/DT3/DT4/DL1
can be selected, select “NULL” indicate that this function is not enabled. Before select the
