2) Gyro Reverse
Set the gyro forward, turn the car right or left to see whether gyro functions. The wheel will
turn left when the car is turned right and the wheel turns right when the car is turned left. If the
gyro acts counter, press the binding button twice, the red LED flashes twice, the gyro reverse is
corrected.
3) Gyro Sensitivity Setup
Gyro sensitivity is default to adjust by channel eight
that default controlled by DL1/PS3 knob switch, turning
the DL1/PS3 knob switch clockwise to increase
sensitivity and anti-clockwise to reduce.
When turning the DL1/PS3 knob switch, tooltip
with yellow background color will pop out at the top of
the screen, and the value of channel will be changing at
the same time, the value is closer to +100, the higher sensitivity. If the value is 0, it means the
gyro function have turned off.
If you want set DL1/PS3 to control other function, you can set another switch such as PS1 to
as the Gain switch setting in the “Channel setting” menu.
Setting steps: turn on the RC8X into home page, click the button at the left bottom of
RC8X into System menu, click into Mixing menu, click the blue select box named Gyro
mixing. Click 1/2 at the top right corner and then Gain switch to assign a switch to control gyro
sensitivity.
Back: click the button or short press the power button to return to the previous menu.
