53
will broadcast the prompt tone that you have selected.
The button at the bottom of the screen is ON, and the background color of the select box is
blue, indicating that when selecting the buzzer or warning voice, the transmitter will not
broadcast the prompt tone that you have selected.
This stops trial listening function only applies to the Key tone-setting menu.
Attention:
PSS indicate that push the steering switch.
PTS indicates the Push throttle switch.
PSxUP: the sound set for the button PS1/PS2/PS3/PS4/PS5 when loosening it.
PSxDOWN: the sound set for the button PS1/PS2/PS3/PS4/PS5 when pressing it.
Back: click the button or short press the power button to return to the previous menu.

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
