RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
55
the word “Snapshot successfully!” will display with
voice broadcast. The screenshot files will save to the
folder named “screenshot” on the SD card. The first
screenshot picture will default named
“Screenshot_0.bmp”, and the number of the file
name will increase by one for each additional picture.
Screenshots preview: it is not supported to
preview screenshots directly in the transmitter.
If you want to preview the screenshots, you can
connect the transmitter and the computer with a
Type-C USB cable, and then preview the screenshots
on the computer. Or pull out the SD card and insert it
into the card reader, and then insert the card reader into the USB port of the computer to
preview the screenshots.
Screenshots preview steps:
1) connect the transmitter and the computer with a Type-C USB cable, and then press the
button PS1 and press the power button at the same time to turn on the transmitter, a tooltip will
pop out, if the yellow select box at USB MODEL, press the power button to make the USB
connect. A U disk will pop out when connecting success.

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
