RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
89
Quick/Slow: +100 indicates the quick throttle curve
rate, and -100 indicates the slow throttle curve rate. The
vertical cursor line moves in conjunction with the
operation of the throttle trigger.
EXP rate: the initial value of EXP rate is 0%, -100% to
+100% can be selected. If you want to make the throttle
high side direction servo operation quicker or milder, click
“+” to increase the value, or click “-“ to decrease the
value. When the value of EXP is not 0%, click Quick or Slow
to switch the value quickly.
VTR curve: It is used to adjust the throttle operates
change with a linear curve from the neutral point to the
high point.
Quick/Slow: +100 indicates the quick throttle curve
rate, and -100 indicates the slow throttle curve rate. The
vertical cursor line moves in conjunction with the
operation of the throttle trigger.
VTR rate: the initial value of VTR rate is 0%, -100% to
+100% can be selected. If you want to make the throttle

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
