Remote Commands Reference
R&S
®
RTC1000
211User Manual 1335.7352.02 ─ 02
Return values:
<Catalog> ENGLish | GERMan | FRENch | SPANish | RUSSian |
SCHinese | TCHinese | JAPanese | KORean
Usage: Query only
13.5.1.2 XY-Setup
DISPlay:XY:XSOurce..................................................................................................... 211
DISPlay:XY:Y1Source.................................................................................................... 211
DISPlay:XY:XSOurce <Source>
Defines the source to be displayed in x direction in an XY-diagram, replacing the usual
time base.
Parameters:
<Source> CH1 | CH2
*RST: CH1
DISPlay:XY:Y1Source <Source>
Defines the (first) source to be displayed in y direction in an XY-diagram.
Parameters:
<Source> CH1 | CH2
*RST: CH2
13.5.1.3 Intensities
DISPlay:INTensity:WAVeform......................................................................................... 211
DISPlay:INTensity:BACKlight.......................................................................................... 212
DISPlay:INTensity:GRID.................................................................................................212
DISPlay:PERSistence:STATe..........................................................................................212
DISPlay:PERSistence:TIME............................................................................................212
DISPlay:PERSistence:INFinite.........................................................................................212
DISPlay:PERSistence:TIME:AUTO.................................................................................. 213
DISPlay:PERSistence:CLEar.......................................................................................... 213
DISPlay:INTensity:WAVeform <Intensity>
Defines the strength of the waveform line in the diagram. *RST does not change the
intensity.
Parameters:
<Intensity> Value in percent
Range: 0 to 100
