This function works in the same manner as the operating panel error reset
function does, which allows remote error reset. "External RESET input" de-
pends on the edge of the input signal (signal changes from inactive to active).
● 22: The second run command source enabled
This function is used to switch RUN / STOP command source between the
first channel (b1.02) and the second channel (b1.17). When this terminal is
inactive, the first channel (b1.02) is active; when this terminal is active, the
second channel (b1.17) is active.
If the external digital input terminal which has been set as "22: The second
run command source enabled" is activated while the frequency converter is in
RUN state, the frequency converter will freewheel to stop.
● 23: Forward (FWD)
● 24: Reverse (REV)
These two functions are used for RUN / STOP command control, see parame-
ter E0.00.
● 25: Forward jogging
● 26: Reverse jogging
For jogging functions, see parameters S3.00 ~ S3.02.
● 27: Counting input
● 28: Counting clear
The above two functions are counting functions of an external signal. See pa-
rameters E1.13 and E1.14.
8.6.2 Analog Input Channel Gain
E0.10 Analog input voltage (AIV) channel gain Kv
Setting range 0.00 ~ 10.00
Minimum unit 0.01
Factory default 1.00
E0.12 Analog input current (AIC) channel gain Kc
Setting range 0.00 ~ 10.00
Minimum unit 0.01
Factory default 1.00
E0.11, E0.13 ~ E0.14: Reserved
