REXROTH EFC 3600 - EFC 3600 Dimensions

5.2 EFC 3600 Dimensions
Frame
EFC 3600
model
①
Dimensions [mm]
Screw
size
②③
Net
weight [kg]
B b H h h1 Ød D T t
A 0K40-1P2 90 80 135 125 146 4.5 113 105 5 M4 0.96
B
0K40-3P4
95 85 145 135 156 4.5 128 120 5 M4
1.18
0K75-1P2 1.24
0K75-3P4 1.26
C
1K50-1P2
95 85 185 175 196 4.5 133 125 5 M4
1.61
1K50-3P4 1.52
D
2K20-1P2
120 110 210 200 221 4.5 138 130 5 M4
2.35
2K20-3P4 2.25
4K00-3P4 2.36
Tab. 5-1: EFC 3600 dimensions
①
: The complete type code for a frequency converter is:
EFC3600-xKxx-xPx-xDA-7P-NNNN, see chapter 17.3 "Appendix 3:
Type Coding" on page 242.
②
: 2 screws are needed for mounting of EFC 3600 frame A, B or C.
③
: 4 screws are needed for mounting of EFC 3600 frame D.
