REXROTH EFC 3600 - Group H0: Communication

17.2.12 Group H0: Communication
General communication configuration
Code Name Setting range Min. unit Default Attri.
H0.00 Communication protocol
0: ModBus
1: ModBus / PROFIBUS
①
1 0 STOP
H0.01 Baud rate
0: 1200 bps
1: 2400 bps
2: 4800 bps
3: 9600 bps
4: 19200 bps
5: 38400 bps
1 3 STOP
H0.02 Data format 0 ~ 3 1 0 STOP
H0.03 Local address
ModBus: 1 ~ 247
PROFIBUS: 1 ~ 126
1 1 STOP
H0.08
Communication disruption
detection time
0.0 ~ 60.0s (0.0s: invalid) 0.1s 0.0s STOP
H0.09
Communication disruption
action
0: Freewheeling to stop
1: Keep running
1 1 STOP
H0.10 PZD3 setting 0 ~ 20 1 0 STOP
H0.11 PZD4 setting 0 ~ 20 1 0 STOP
H0.12 PZD5 setting 0 ~ 20 1 0 STOP
H0.13 PZD6 setting 0 ~ 20 1 0 STOP
H0.14 PZD7 setting 0 ~ 20 1 0 STOP
H0.15 PZD8 setting 0 ~ 20 1 0 STOP
H0.16 PZD9 setting 0 ~ 20 1 0 STOP
H0.17 PZD10 setting 0 ~ 20 1 0 STOP
H0.04 ~ H0.07 Reserved
①
: it is ModBus for EFC3600-xKxx-xPx-MDA-7P-NNNN models; it is
PROFIBUS for EFC3600-xKxx-xPx-PDA-7P-NNNN models.
Setting range of H0.02:
0: N, 8, 1 (1 start bit, 8 data bits, 1 stop bit, no check)
1: E, 8, 1 (1 start bit, 8 data bits, 1 stop bit, even parity)
2: O, 8, 1 (1 start bit, 8 data bits, 1 stop bit, odd parity)
3: N, 8, 2 (1 start bit, 8 data bits, 1 stop bit, no parity)
