12.4.3 Electrical data
Description 1400-N0005 1000-N0007 0700-N0010 0470-N0015
Rated voltage
AC 380 V /50 Hz
Rated current [A] 5 7 10 15
Rated inductance [mH] 1.4 1.0 0.7 0.47
Dielectric strength 3,000 V / 5 mA / 10s
Insulation resistance ≥ 100 MΩ
Tab. 12-9: Electrical data
12.5 Communication Interface
12.5.1 RS485/RS232 Adapter
RS232/RS485 adapter (FEAA01.1-RS485-RS232-NNNN-NN, see chapter 17.3
"Appendix 3: Type Coding" on page 242) is used to connect the RS485 interface
(ModBus) with RS232 interface of a PC or other control units.
12.5.2 Cable for RS485/RS232 Adapter
The cable FRKB0002/005,0, which is 1 m long (see chapter 17.3 "Appendix 3:
Type Coding" on page 242), is used to connector the frequency converter to the
RS485/232 adapter.
12.6 Operating Panel Cable for Control Cabinet Mounting
12.6.1 Control Cabinet Mounting Plate
The operating panel (FPCC, see fig. 17-2 "Operating panel type coding" on page
243) is mounted at the control cabinet. The user can operate and control the
frequency converter from the outside of the control cabinet conveniently. To re-
alize this function, the user needs order the mounting plate (FVAM, see fig. 17-9
"Operating panel mounting plate for control cabinet" on page 248) for control
cabinet mounting and its accessories additionally.
EFC 3600
Bosch Rexroth AG
Accessories
DOK-RCON03-EFC-3600***-IT03-EN-P
179/259
