Construction
Degrees of protection IP 20 (Mounting on the metal wall in control cabinet)
Cooling type Natural cooling (≤ 0K75); Enforced air cooling (≥ 1K50)
Standards and certifications
CE, UL, RCM
Mounting mode
Wall mounting
Tab. 10-1: General technical data
10.2 Electrical Data
1-phase 200 V series
Model EFC 3600-□□□□-1P2-xDA-7P-NNNN 0K40 0K75 1K50 2K20 –
Power class [kW] 0.4 0.75 1.5 2.2 –
Rated input current [A] 5.8 9.6 15.0 19.7 –
200 V rated output current [A] 2.3 3.9 7.0 9.7 –
240 V rated output current [A] 1.9 3.3 5.8 8.1 –
Rated output apparent power [kVA] 0.8 1.4 2.4 3.4 –
3-phase 400 V series
Model EFC 3600-□□□□-3P4-xDA-7P-NNNN 0K40 0K75 1K50 2K20 4K00
Power class [kW] 0.4 0.75 1.5 2.2 4.0
Rated input current [A] 1.3 2.3 3.9 5.6 9.8
380 V rated output current [A] 1.2 2.1 3.7 5.1 8.8
480 V rated output current [A] 1.0 1.6 2.9 4.0 7.0
Rated output apparent power [kVA] 0.8 1.4 2.4 3.4 5.8
Tab. 10-2: Electrical data
□□□□: is a substitute for different power.
● i.e. 0K40 means 0.4 kW.
10.3 Derating of Electrical Data
10.3.1 Derating and Ambient Temperature
The ambient temperature for EFC 3600 is -10 ~ 50 ℃.
● If the ambient temperature is within this range, there will be no need for de-
rating.
● If the ambient temperature is out of this range, there will be no possibility to
install and run the frequency converter, even the performance data have been
additionally reduced.
EFC 3600
Bosch Rexroth AG
Technical Data
DOK-RCON03-EFC-3600***-IT03-EN-P
139/259
