17 Appendix
17.1 Appendix 1: Abbreviations
Rexroth EFC 3600 Frequency Converter drive system is composed of individual
parts (components) for application in different circumstances.
● EFC 3600: EFC 3600 frequency converter
● FPCC: Operating panel
● FENL: Mains choke
● FENF: External EMC filter
●
FEAA: Interface adapter
● FRKB: Interface adapter cable
● FRKS: Operating panel cable
● FSAM: Operating panel mounting plate for control cabinet
● FELR: Brake resistor
● FEML: Motor choke
17.2 Appendix 2: Parameter List
17.2.1 Description of Attribute Symbols in Parameter Tables
Parameter attribute Description
RUN/STOP
Parameter setting can be modified when the frequency converter is in RUN
or STOP mode.
STOP
Parameter setting can only be modified when the frequency converter is in
STOP mode.
mpwd
Parameter setting can only be modified when the manufacturer password
protection is disabled.
read only Parameter setting is read-only and cannot be modified.
Tab. 17-1: Description of attribute symbols in parameter tables
● Code: means function / parameter code, written in bx.xx, Ex.xx,
Sx.xx, Hx.xx and dx.xx.
● Value of function / parameter code: written in [bx.xx], [Ex.xx],
[Sx.xx], [Hx.xx], and [dx.xx].
● Default: values that correspond to the factory default upon initiali-
zation at 50 Hz.
● Attri.: means attribute.
