REXROTH EFC 3600 - Group E2: Multi-Speed and Simple PLC

17.2.9 Group E2: Multi-speed and Simple PLC
Acceleration/deceleration time 2, 3 and 4
Code Name Setting range Min. unit Default Attri.
E2.00 Acceleration time 2
0.1 ~ 6,000.0s
0.1s 10.0s RUN/STOP
E2.01 Deceleration time 2 0.1s 10.0s RUN/STOP
E2.02 Acceleration time 3 0.1s 10.0s RUN/STOP
E2.03 Deceleration time 3 0.1s 10.0s RUN/STOP
E2.04 Acceleration time 4 0.1s 10.0s RUN/STOP
E2.05 Deceleration time 4 0.1s 10.0s RUN/STOP
E2.06 ~ E2.09 Reserved
Multi-speed frequency
Code Name Setting range Min. unit Default Attri.
E2.10 Multi-speed frequency 1
0.00 Hz ~ [b1.06]
0.01 Hz 0.00 Hz RUN/STOP
E2.11 Multi-speed frequency 2 0.01 Hz 0.00 Hz RUN/STOP
E2.12 Multi-speed frequency 3 0.01 Hz 0.00 Hz RUN/STOP
E2.13 Multi-speed frequency 4 0.01 Hz 0.00 Hz RUN/STOP
E2.14 Multi-speed frequency 5 0.01 Hz 0.00 Hz RUN/STOP
E2.15 Multi-speed frequency 6 0.01 Hz 0.00 Hz RUN/STOP
E2.16 Multi-speed frequency 7 0.01 Hz 0.00 Hz RUN/STOP
E2.17 ~ E2.29 Reserved
Simple PLC basic control
Code
Name Setting range Min. unit Default Attri.
E2.30 Simple PLC running mode
0: No action; 1: Mode 1
2: Mode 2; 3: Mode 3
1 0 STOP
E2.31 Simple PLC time multiplier 1 ~ 60 1 1 STOP
E2.32 ~ E2.34 Reserved
