PLC stage control
Code Name Setting range Min. unit Default Attri.
E2.35 Stage 0 action selection
011, 012, 013, 014, 021,
022, 023, 024, 031, 032,
033, 034, 041, 042, 043,
044, 111, 112, 113, 114,
121, 122, 123, 124, 131,
132, 133, 134, 141, 142,
143, 144
1 011 STOP
E2.37 Stage 1 action selection 1 011 STOP
E2.39 Stage 2 action selection 1 011 STOP
E2.41 Stage 3 action selection 1 011 STOP
E2.43 Stage 4 action selection 1 011 STOP
E2.45 Stage 5 action selection 1 011 STOP
E2.47 Stage 6 action selection 1 011 STOP
E2.49 Stage 7 action selection 1 011 STOP
E2.36 Stage 0 running time
0.0 ~ 6,000.0s
0.1s 20.0s STOP
E2.38 Stage 1 running time 0.1s 20.0s STOP
E2.40 Stage 2 running time 0.1s 20.0s STOP
E2.42 Stage 3 running time 0.1s 20.0s STOP
E2.44 Stage 4 running time 0.1s 20.0s STOP
E2.46 Stage 5 running time 0.1s 20.0s STOP
E2.48 Stage 6 running time 0.1s 20.0s STOP
E2.50 Stage 7 running time 0.1s 20.0s STOP
E2.51 ~ E2.70 Reserved
