REXROTH EFC 3600 - Group E4: Error and Protection

17.2.11 Group E4: Error and Protection
Protection configuration
Code Name Setting range Min. unit Default Attri.
E4.01 Overvoltage prevention setting 0 ~ 2 1 0 STOP
E4.02
Stall overvoltage prevention
level
200V class: 300 ~ 390 V
400V class: 600 ~ 885 V
1 V
390 V
885 V
STOP
E4.03
Stall overcurrent prevention
level
20.0 % ~ 200.0 % (of rat-
ed frequency converter
output current)
0.1 % 200.0 % STOP
E4.04 Low speed derating frequency 0.10 ~ 300.00 Hz 0.01 Hz 25.00 Hz RUN/STOP
E4.05 Zero speed load 25.0 % ~ 100.0 % 0.1 % 25.0 % RUN/STOP
E4.06 Phase loss protection 0 ~ 3 1 3 RUN/STOP
E4.00, E4.07 ~ E4.14 Reserved
Setting range of E4.01:
0: Both disabled
1: Stall protection enabled, braking disabled
2: Stall protection disabled, braking enabled
Setting range of E4.06:
0: Both input and output phase loss protection active
1: Only input phase loss protection active
2: Only output phase loss protection active
3: Both input and output phase loss protection inactive
Error reset
Code
Name Setting range Min. unit Default Attri.
E4.15 Number of error reset attempts 0 ~ 3 (0: No auto reset) 1 0 STOP
E4.16 Interval between reset attempts 2 ~ 60s 1s 10s STOP
E4.17 ~ E4.19 Reserved
EFC 3600 Bosch Rexroth AG
Appendix
DOK-RCON03-EFC-3600***-IT03-EN-P
237/259
