17.2.13 Group d: Monitoring Parameters
Monitoring parameters
Code Name Setting range Min. unit Default Attri.
d0.00 Output frequency 0.00 ~ 400.00 Hz 0.01 Hz 0.00 Hz read only
d0.01 Output velocity 0 ~ 65535 rps 1 rps 0 rps read only
d0.02 Setting frequency 0.00 ~ 400.0 Hz 0.01 Hz 0.00 Hz read only
d0.03 Setting velocity 0 ~ 65535 rps 1 rps 0 rps read only
d0.04 Output voltage 0 ~ 480 V 1 V 0 V read only
d0.05 Output current 0.0 ~ 1,000.0 A 0.1 A 0.0 A read only
d0.06 Output power 0.0 ~ 1,000.0 kW 0.1 kW 0.0 kW read only
d0.07 DC bus voltage 0 ~ 800 V 1 V 0 V read only
d0.08 Analog input AIV 0.0 ~ 10.0 V 0.1 V 0.0 V read only
d0.09 Analog input AIC 0.0 ~ 20.0 mA 0.1 mA 0.0 mA read only
d0.10 Self-defined setting velocity 0.0 ~ 6,000.0 0.1 0.0 read only
d0.11 Self-defined output velocity 0.0 ~ 6,000.0 0.1 0.0 read only
d0.12 Digital input status 0 ~ 31 1 0 read only
d0.13 Digital output status 0 ~ 3 1 0 read only
d0.14 PID reference engineering value 0.0 ~ 6,000.0 0.1 0.0 read only
d0.15 PID feedback engineering value 0.0 ~ 6,000.0 0.1 0.0 read only
d0.16 Module temperature – 1 0 read only
d0.17 Software version 1 0.00 ~ 99.99 0.01
Depends on
model
read only
d0.18 Software version 2 0.00 ~ 99.99 0.01 read only
d0.19 Software version 3 0.00 ~ 99.99 0.01 read only
d0.20 Actual carrier frequency 1 ~ 15 kHz 1 kHz read only
d0.70 High resolution output current 0.00 ~ 300.00 A 0.01 A read only
d0.71 Boot-Loader software version 0.00 ~ 99.99 0.01 read only
