17.2.7 Group E0: Input Terminals
Multi-function digital input terminals
Code Name Setting range Min. unit Default Attri.
E0.00 2-wire/3-wire running control
0: Forward/stop, reverse/stop
1: Forward/reverse, run/stop
2: 3-wire control
1 0 STOP
E0.01 Terminal X1
0 ~ 28
1 0 STOP
E0.02 Terminal X2 1 0 STOP
E0.03 Terminal X3 1 0 STOP
E0.04 Terminal X4 1 0 STOP
E0.05 Terminal X5 1 0 STOP
E0.06 ~ E0.09 Reserved
Setting range of E0.01 ~ E0.05:
0: No action (multiple choices allowed)
1: Multi-speed control terminal 1
2: Multi-speed control terminal 2
3: Multi-speed control terminal 3; 4: Reserved
5: Acceleration/deceleration time terminal 1
6: Acceleration/deceleration time terminal 2
7: 3-wire running control
8: Freewheeling to stop enabled
9: Frequency increment UP command
10: Frequency decrement DOWN command
11: Zeroing of external terminal frequency setting; 12: Reserved
13: Stopping DC braking enabled; 14: Reserved
15: Simple PLC prohibited; 16: Simple PLC paused; 17: Reserved
18: The second frequency command source enabled
19: External error N.O. contact input
20: External error N.C. contact input
21: External RESET input
22: The second run command source enabled
23: Forward (FWD); 24: Reverse (REV)
25: Forward jogging; 26: Reverse jogging
27: Counting input; 28: Counting clear
