Skip frequency
Code Name Setting range Min. unit Default Attri.
S3.05 Skip frequency 1 0.00 Hz ~ [b1.06] 0.01 Hz 0.00 Hz STOP
S3.06 Skip frequency 2 0.00 Hz ~ [b1.06] 0.01 Hz 0.00 Hz STOP
S3.07 Skip frequency 3 0.00 Hz ~ [b1.06] 0.01 Hz 0.00 Hz STOP
S3.08 Skip frequency range 0.00 ~ 30.00 Hz 0.01 Hz 0.00 Hz STOP
S3.09
Skip frequency window accelera-
tion factor
1 ~ 100 1 1 STOP
S3.10 ~ S3.14 Reserved
Restarting after power fault
Code Name Setting range Min. unit Default Attri.
S3.15 Restarting after power fault 0: Prohibited; 1: Allowed 1 0 STOP
S3.16
Waiting time for restarting after
power fault
0.0 ~ 10.0s 0.1s 1.0s STOP
S3.17 ~ S3.19 Reserved
Brake chopper control
Code Name Setting range Min. unit Default Attri.
S3.20 Brake chopper action point
200 V class: 300 ~ 390 V
1 V
390 V
STOP
400 V class: 600 ~ 885 V 885 V
S3.21 Braking duty cycle 1 % ~ 100 % 1 % 100 % STOP
S3.22 ~ S3.29, S3.31 Reserved
Additional running control
Code
Name Setting range Min. unit Default Attri.
S3.30
Forward and reverse rota-
tion dead zone time
0.0 ~ 60.0s 0.1s 4.0s STOP
S3.32 UP/DOWN set velocity 0.10 ~ 100.00 Hz/s 0.01 Hz/s 1.00 Hz/s RUN/STOP
S3.33
UP/DOWN terminals initial
frequency
0.00 Hz ~ [b1.06] 0.01 Hz 0.00 Hz RUN/STOP
S3.34 Fan control
0: Automatically controlled
1: Always on
1 0 RUN/STOP
S3.35 Stopping with Stop key
0: Only valid for operating
panel control
1: Valid for all control means
1 0 RUN/STOP
