8.6.3 Analog Input Filtering Time
E0.15 Analog channel filtering time
Setting range 0.000 ~ 2.000s
Minimum unit 0.001s
Factory default 0.100s
E0.16 ~ E0.19: Reserved
8.6.4 Analog Input Curve Configuration
E0.20 Analog setting curve selection
Setting range
0: AIC-reference characteristic curve 1, AIV-reference characteristic curve 1
1: AIC-reference characteristic curve 1, AIV-reference characteristic curve 2
2: AIC-reference characteristic curve 2, AIV-reference characteristic curve 1
3: AIC-reference characteristic curve 2, AIV-reference characteristic curve 2
Minimum unit 1
Factory default 0
E0.21 Curve 1 min. reference
Setting range 0.0 % ~ [E0.23]
Minimum unit 0.1 %
Factory default 0.0 %
E0.22 Frequency corresponding to curve 1 min. reference
Setting range 0.00 Hz ~ [b1.06]
Minimum unit 0.01 Hz
Factory default 0.00 Hz
E0.23 Curve 1 max. reference
Setting range [E0.21] ~ 100.0 %
Minimum unit 0.1 %
Factory default 100.0 %
E0.24 Frequency corresponding to curve 1 max. reference
Setting range 0.00 Hz ~ [b1.06]
Minimum unit 0.01 Hz
Factory default 50.00 Hz
E0.25 Curve 2 min. reference
Setting range 0.0 % ~ [E0.27]
Minimum unit 0.1 %
Factory default 0.0 %
E0.26 Frequency corresponding to curve 2 min. reference
