12.2 EMC Filter
12.2.1 The Function of EMC Filter
EMC filters are used to reduce radio interference and mains pollution.
12.2.2 External EMC Filter Type
EFC 3600 model External EMC filter type
0K40-1P2 E0006-A-240
0K75-1P2 E0010-A-240
1K50-1P2 E0020-A-240
2K20-1P2 E0025-A-240
0K40-3P4
E0008-A-480
0K75-3P4
1K50-3P4
2K20-3P4
4K00-3P4 E0020-A-480
Tab. 12-3: External EMC filter type
● For definition of model or type, see chapter 17.3 "Appendix 3:
Type Coding" on page 242.
● The EMC filters listed above are recommended based on tests
with 5 m motor cables. If longer motor cables are needed, please
use appropriate EMC filters.
12.2.3 Technical Data
Dimensions
Mounting position and distances
Only the mounting position G1 is allowed for EMC filter FENF.
Keep at least 80 mm at the top side and bottom side of EMC filter
free from mounted parts.
