[d0.15] = PID feedback x [b0.33]
With:
[d0.15]: PID feedback engineering value
[b0.33]: PID reference / feedback coefficient
Users may convert the PID engineering value to any other form they feel easy to
understand via parameter b0.33.
In case the value of a monitoring parameter is too big to fit into the
4-digit display:
● If the display value is between 1,000.0 and 9,999.9, 1000 ~ 9999
is displayed without the display of the decimal point.
● If the display value is not less than 10,000, the higher 4 digits are
displayed and the rightmost decimal point is lit to indicate that
one more digit is hidden to the right, for example: "12340" is dis-
played as "1234.".
b0.34 Time constant for high resolution output current
Setting range 5 ~ 500 ms
Minimum unit 1 ms
Factory default 40 ms
b0.35 ~ b0.39: Reserved
Used to set the resolution of dynamic output current in applications where a
high resolution value with two decimals are required for monitoring or control.
8.1.5 System Information
b0.40 Cumulative running time
Setting range 0 ~ 65535 hours
Minimum unit 1 hour
Factory default 0 hour
b0.41 ~ b0.49: Reserved
Used to display the switching-on time of a frequency converter. When the cumu-
lative running time exceeds 65535 hours, the counter remains at 65535.
Bosch Rexroth AG
Parameter Settings
EFC 3600
52/259
DOK-RCON03-EFC-3600***-IT03-EN-P
