8.7.4 External Signal Counter
E1.13 Middle count value
Setting range 0 ~ [E1.14]
Minimum unit 1
Factory default 0
E1.14 Target count value
Setting range [E1.13] ~ 9999
Minimum unit 1
Factory default 0
E1.15 ~ E1.29: Reserved
The corresponding digital output for "Middle / Target count value reached"
should be configured, see details in E1.00 and E1.02.
After the counter has reached its Middle /Target value [E1.13] / [E1.14], it re-
mains at this value till it is reset by a valid edge of the input terminal signal para-
meterized as “clear counting”. As long as the counter value is not reset, the digi-
tal outputs configured as “DOutx=16: Target counter value reached” and
“DOutx=17: Middle counter value reached” remain active. These signals are re-
set by the next valid triggering edge of the input terminal signal parameterized
as “counting signal input” after the counter value is cleared.
● If one of the parameters E1.13, E1.14 and / or digital input termi-
nal configuration E0.01 ~ E0.05 is changed, the counter value is
reset and digital outputs defined as “DOutx=16: Target counter
value reached” and “DOutx=17: Middle counter value reached”
are inactive immediately;
● The maximum allowed frequency of digital input is 50 Hz and the
minimum allowed pulse width (both active and inactive) should
be longer than 8ms.
