REXROTH EFC 3600 - Group B1: Basic Parameters

17: Firmware version 1
18: Firmware version 2
19: Firmware version 3
20: Actual carrier frequency
70: High resolution output current
System information
Code Name Setting range Min. unit Default Attri.
b0.40 Cumulative running time 0 ~ 65535 hours 1 hour 0 mpwd
b0.41 ~ b0.49 Reserved
17.2.3 Group b1: Basic Parameters
Basic running control
Code Name Setting range Min. unit Default Attri.
b1.00 First frequency setting source 0 ~ 6 1 0 STOP
b1.01 Digital set frequency saving 0 ~ 3 1 0 STOP
b1.02 First RUN command source 0 ~ 2 1 0 STOP
b1.04 Digital set frequency 0.00 Hz ~ [b1.06] 0.01 Hz 50.00 Hz RUN/STOP
b1.05 Max. frequency 50.00 ~ 400.00 Hz 0.01 Hz 50.00 Hz STOP
b1.06 Upper frequency [b1.07] ~ [b1.05] 0.01 Hz 50.00 Hz RUN/STOP
b1.07 Lower frequency 0.00 Hz ~ [b1.06] 0.01 Hz 0.00 Hz RUN/STOP
b1.08 Lower frequency mode
0: Running with 0 Hz
1: Run with lower frequency
1 0
STOP
b1.09 Hysteresis frequency width 0.00 Hz ~ [b1.07] 0.01 Hz 0.00 Hz
b1.10 Direction control
0: Both directions
1: Forward only
2: Reverse only
3: Inverse default direction
1 0 STOP
b1.11
Operating panel control di-
rection
0: Forward; 1: Reverse 1 0 RUN/STOP
b1.15
Combination frequency com-
mand source
0 ~ 2 1 0 STOP
b1.16
Second frequency setting
source
0 ~ 6 1 2 STOP
