Code Name Setting range Min. unit Default Attri.
b1.17
Second RUN command
source
0 ~ 2 1 1 STOP
b1.03, b1.12 ~ b1.14, b1.18 ~ b1.19 Reserved
Setting range of b1.00 and b1.16:
0: Given by panel potentiometer
1: Given by panel digital setting
2: Given by external analog input voltage (AIV)
3: Given by external analog input current (AIC)
4: Given by external UP / DOWN terminals
5: Given by communication
6: Given by multi-speed
Setting range of b1.01:
0: Not saved when powered off or stopped
1: Not saved when powered off; saved when stopped
2: Saved when powered off; not saved when stopped
3: Saved when powered off or stopped
Setting range of b1.02 and b1.17:
0: Inputting commands by operating panel
1: Inputting commands by external terminals
2: Inputting commands by communication
Setting range of b1.15:
0: No combination
1: First frequency setting+ second frequency setting
2: First frequency setting - second frequency setting
Acceleration/deceleration control
Code
Name Setting range Min. unit Default Attri.
b1.20 Acceleration time 1 0.1 ~ 6,000.0s 0.1s 5.0s RUN/STOP
b1.21 Deceleration time 1 0.1 ~ 6,000.0s 0.1s 5.0s RUN/STOP
b1.22 Acceleration / deceleration curve mode
0: Linear mode
1: S-curve
1 0 STOP
b1.23 S curve starting phase proportion 0.0 % ~ 40.0 % 0.1 % 20.0 % STOP
b1.24 S curve stopping phase proportion 0.0 % ~ 40.0 % 0.1 % 20.0 % STOP
b1.25 ~ b1.29 Reserved
