Starting configuration
Code Name Setting range Min. unit Default Attri.
b1.30 Starting mode
0: Start directly
1: Braking before start
2: Start with speed capture
1 0 STOP
b1.31 Starting frequency 0.00 ~ 50.00 Hz 0.01 Hz 0.05 Hz STOP
b1.32
Starting frequency
holding time
0.0 ~ 20.0s 0.1s 0.1s STOP
b1.33
Starting DC braking
time
0.0 ~ 20.0s (0.0s: no action of starting
DC braking)
0.1s 0.0s STOP
b1.34
Starting DC braking
current
0.0 % ~ 150.0 %
(of rated frequency converter current)
0.1 % 0.0 % STOP
b1.35 ~ b1.39 Reserved
Stopping configuration
Code Name Setting range Min. unit Default Attri.
b1.40 Stopping mode
0: Decelerating to stop
1: Freewheeling to stop
2: Freewheeling with STOP-command,
decelerating when direction changes
1 0 STOP
b1.41
Stopping DC braking
initial frequency
0.00 ~ 50.00 Hz 0.01 Hz 0.00 Hz STOP
b1.42
Stopping DC braking
time
0.0 ~ 20.0s (0.0 represents no action
of stopping DC braking)
0.1s 0.0s STOP
b1.43
Stopping DC braking
current
0.0 % ~ 150.0 %
(of rated frequency converter current)
0.1 % 0.0 % STOP
b1.44 Reserved – – – –
b1.45 Over excitation gain 1.00 ~ 1.40 0.01 1.00 RUN/STOP
b1.46 ~ b1.49 Reserved
