5.9 Cable and Fuse Dimensions
5.9.1 Selection Standards
The power cable dimensions and the fuse dimensions are based on the VDE
0298 (part 4) and the standard for the European countries EN 60204-1.
The dimension for flexible wiring is according to VDE 0298 (part 4) and for fix
wiring according to VDE 0298 (part 4) or IEC 60364-5 (operating temperature at
the conductor 90 ℃).
The cable and fuse dimensions for USA / Canada are based on UL 508A.
The manufacturer of the machine/installation is responsible for con-
formity with regional provisions and other standards that are rele-
vant for the respective application and the place of installation. Also
factors, such as installation methods, grounding, insulation and
over-voltage protection must be taken into consideration.
National standards, such as NFPA in the USA, regional provisions, ground, ope-
rating temperature, operating cycles, over-voltage protection and system config-
uration can have a decisive impact on the dimensioning of the cables and there-
fore they must be given priority over the above factors.
If, as a consequence of this, further requirement and cable designs
arise that are not mentioned in this documentation, contact your
Bosch Rexroth sales partner.
Bosch Rexroth AG
Mounting and Installation
EFC 3600
28/259
DOK-RCON03-EFC-3600***-IT03-EN-P
