17.2.8 Group E1: Output Terminals
Multi-function output terminals
Code Name Setting range Min. unit Default Attri.
E1.00 OUT1 output 0: Frequency converter ready for running
1: Frequency converter is running
2: DC braking indication
3: Frequency converter running at zero speed
4: Frequency/speed arrival signal
5: Frequency level detection signal (FDT1)
6: Frequency level detection signal (FDT2)
7: Simple PLC phase completion indication
8: Simple PLC cycle completion indication
9: Reserved
10: Under voltage indication
11: Frequency converter overload pre-warning
12: Motor overload pre-warning
13: Stopped by external error
14: Error output
15: Reserved
16: Target counter value reached
17: Middle counter value reached
18: PID reference engineering value reached tol-
erance
1 1 STOP
E1.02 Relay output
E1.01, E1.03 Reserved
Frequency detection
Code
Name Setting range Min. unit Default Attri.
E1.04 Frequency arriving at detection width 0.00 ~ 400.0 Hz 0.01 Hz 2.50 Hz RUN/STOP
E1.05 Frequency detection level FDT1 0.00 ~ 400.0 Hz 0.01 Hz 50.00 Hz RUN/STOP
E1.06 Frequency detection level FDT1 width 0.00 Hz ~ [E1.05] 0.01 Hz 1.00 Hz RUN/STOP
E1.07 Frequency detection level FDT2 0.00 ~ 400.0 Hz 0.01 Hz 25.00 Hz RUN/STOP
E1.08 Frequency detection level FDT2 width 0.00 Hz ~ [E1.07] 0.01 Hz 1.00 Hz RUN/STOP
