Overload pre-warning
Code Name Setting range Min. unit Default Attri.
E1.09
Frequency converter over-
load pre-warning level setting
20.0 % ~ 200.0 % (of rated
frequency converter cur-
rent)
0.1 % 110.0 % STOP
E1.10
Motor overload pre-warning
level setting
100.0 % ~ 250.0 %
(of rated motor current)
0.1 % 100.0 % RUN/STOP
E1.11
Frequency converter over-
load pre-warning delay
0.0 ~ 20.0s 0.1s 2.0s RUN/STOP
E1.12
Motor overload pre-warning
delay
0.0 ~ 20.0s 0.1s 2.0s RUN/STOP
External signal counter
Code Name Setting range Min. unit Default Attri.
E1.13 Middle count value 0 ~ [E1.14] 1 0 RUN/STOP
E1.14 Target count value [E1.13] ~ 9999 1 0 RUN/STOP
E1.15 ~ E1.29 Reserved
Analog output terminal
Code Name Setting range Min. unit Default Attri.
E1.30 FM1 analog output selection
0: Running frequency
1: Set frequency
2: Output current
3: Reserved
4: Output voltage
5: Output power
6: Analog input voltage
7: Analog input current
1 0 RUN/STOP
E1.31 FM1 channel mode
0: 0 ~ 10 V
1: 2 ~ 10 V
1 0 RUN/STOP
E1.32 FM1 gain setting 0.00 ~ 10.00 0.01 1.00 RUN/STOP
E1.33 ~ E1.40 Reserved
