8.4 Group S2: Motor Parameters
8.4.1 Motor Nameplate Parameters
S2.00 Rated motor frequency
Setting range 5.00 ~ 400.00 Hz
Minimum unit 0.01 Hz
Factory default 50.00 Hz
S2.01 Rated motor rotation speed
Setting range 1 ~ 30,000 rpm
Minimum unit 1 rpm
Factory default Depends on model
S2.02 Rated motor power
Setting range 0.1 ~ 1,000.0 kW
Minimum unit 0.1 kW
Factory default Depends on model
S2.03 Rated motor voltage
Setting range 0 ~ 480 V
Minimum unit 1 V
Factory default Depends on model
S2.04 Rated motor current
Setting range 0.01 ~ 655.00 A
Minimum unit 0.01 A
Factory default Depends on model
S2.05 Power-factor
Setting range 0.50 ~ 0.95
Minimum unit 0.01
Factory default Depends on model
S2.06 ~ S2.09: Reserved
