REXROTH EFC 3600 - Overload Pre-Warning

8.7.3 Overload Pre-warning
E1.09 Frequency converter overload pre-warning level setting
Setting range 20.0 % ~ 200.0 % (of rated frequency converter current)
Minimum unit 0.1 %
Factory default 110.0 %
E1.10 Motor pre-warning level setting
Setting range 100.0 % ~ 250.0 % (of rated motor current)
Minimum unit 0.1 %
Factory default 100.0 %
When the output current exceeds the threshold defined in E1.09 for delay time
defined in E1.11, the function is active. The signal is immediately deactivated
when the output current is lower than the threshold defined in E1.09.
E1.11 Frequency converter overload pre-warning delay
Setting range 0.0 ~ 20.0s
Minimum unit 0.1s
Factory default 2.0s
E1.12 Motor overload pre-warning delay
Setting range 0.0 ~ 20.0s
Minimum unit 0.1s
Factory default 2.0s
When the output current exceeds the threshold defined in E1.10 for delay time
defined in E1.12, the function is active. The signal is immediately deactivated
when the output current is lower than the threshold defined in E1.10.
