REXROTH EFC 3600 - Group S2: Motor Parameters

No-trip control
Code Name Setting range Min. unit Default Attri.
S0.30 Current limitation control
0: OFF
1: OFF at constant speed
3: ON at constant speed
1 0 STOP
S0.31
Automatic current limitation
level
20 % ~ 250 % (of rated fre-
quency converter current)
1 % 200 % STOP
S0.32
Current regulator proportion
factor
0.000 ~ 1.000 0.001 0.060 STOP
S0.33
Current regulator integrating
time constant
0.001 ~ 10.000 0.001 0.200 STOP
17.2.5 Group S2: Motor Parameters
Motor nameplate parameters
Code Name Setting range Min. unit Default Attri.
S2.00 Rated motor frequency 5.00 ~ 400.00 Hz 0.01 Hz 50.00 Hz STOP
S2.01 Rated motor rotation speed 1 ~ 30,000 rpm 1 rpm
Depends
on model
STOP
S2.02 Rated motor power 0.1 ~ 1,000.0 kW 0.1 kW STOP
S2.03 Rated motor voltage 0 ~ 480 V 1 V STOP
S2.04 Rated motor current 0.01 ~ 655.00 A 0.01 A STOP
S2.05 Power-factor 0.50 ~ 0.95 0.01 STOP
S2.06 ~ S2.09 Reserved
EFC 3600 Bosch Rexroth AG
Appendix
DOK-RCON03-EFC-3600***-IT03-EN-P
227/259
