8.8.3 Simple PLC Basic Control
E2.30 Simple PLC running mode
Setting range 0 ~ 3
Minimum unit 1
Factory default 0
● 0: Inactive.
Simple PLC control is inactive.
● 1: Mode 1.
Simple PLC stops after one cycle. In this mode, the frequency converter de-
celerates to 0.00 Hz after the last stage and a STOP signal is generated. The
frequency converter stops according to the configured stopping mode.
● 2: Mode 2.
Simple PLC runs in cycle repeatedly and stops when a stopping command is
entered. In this mode, the frequency converter decelerates to 0.00 Hz after
the last stage and then enters into simple PLC cycles again.
● 3: Mode 3.
After one cycle, the frequency converter keeps running at the set frequency of
the last stage.
E2.31 Simple PLC time multiplier
Setting range 1 ~ 60
Minimum unit 1
Factory default 1
E2.32 ~ E2.34: Reserved
The actual running time of each stage=[Stage running time] × [E2.31].
[Stage running time] has a possible maximum value of 6000.0s, the PLC time
multiplier E2.31 has a maximum value of 60 and there are 8 possible stages
(0-7), so the maximum duration of one PLC cycle calculates to: 8 × 6000.0s ×
60=800 hours.
8.8.4 PLC Stage Control
E2.35 Stage 0 action selection
Setting range
011, 012, 013, 014, 021, 022, 023, 024, 031, 032, 033, 034, 041, 042,
043, 044, 111, 112, 113, 114, 121, 122, 123, 124, 131, 132, 133, 134,
141, 142, 143, 144
Minimum unit 1
Factory default 011
E2.36 Stage 0 running time
Setting range 0.0 ~ 6,000.0s
Bosch Rexroth AG
Parameter Settings
EFC 3600
108/259
DOK-RCON03-EFC-3600***-IT03-EN-P
