8.7 Group E1: Output Terminal Parameters
8.7.1 Multi-function Output Terminals
E1.00 OUT1 output
Setting range 0 ~ 18
Minimum unit 1
Factory default 1
E1.02 Relay output
Setting range 0 ~ 18
Minimum unit 1
Factory default 1
E1.01, E1.03: Reserved
● 0: Frequency converter ready for running
After powering on, if no error happens and there is no run command, output
active indicates that the frequency converter is ready for running.
● 1: Frequency converter is running
The terminal outputs indicating signal when the frequency converter is run-
ning and has frequency output (including 0.00 Hz).
● 2: DC braking indication
When the frequency converter is in the starting or stopping DC braking, out-
put is active.
● 3: Frequency converter running at zero speed
When the frequency converter is running with zero speed, output is active.
During dead zone time of rotation direction change, there is no out-
put for this selection.
● 4: Frequency / speed arrival signal
See related parameter "Frequency arriving at detection width" E1.04.
● 5: Frequency level detection signal (FDT1)
● 6: Frequency level detection signal (FDT2)
See related parameters E1.05 ~ E1.08.
● 7: Simple PLC phase completion indication
When PLC mode [E2.30] = 1, 2 or 3, this terminal outputs a pulse at the end
of every PLC stage. When a stage is finished a pulse is output with the dura-
tion of 0.5s. If one of the stages has a running time of 0.0s, this stage will be
directly jumped over and there will be no pulse output. For details of simple
PLC control, see parameters E2.10 ~ E2.16 and E2.30 ~ E2.50.
Bosch Rexroth AG
Parameter Settings
EFC 3600
98/259
DOK-RCON03-EFC-3600***-IT03-EN-P
