17.2.4 Group S0: V/F control
V/F curve
Code Name Setting range Min. unit Default Attri.
S0.00 V/F curve mode
0: Linear mode
1: Square curve
2: User-defined multipoint curve
1 0 STOP
S0.01 V/F frequency 1 0.00 Hz ~ [S0.03] 0.01 Hz 0.00 Hz STOP
S0.02 V/F voltage 1 0.0 % ~ 120.0 % (of rated motor voltage) 0.10 % 0.00 % STOP
S0.03 V/F frequency 2 [S0.01] ~ [S0.05] 0.01 Hz 0.00 Hz STOP
S0.04 V/F voltage 2 0.0 % ~ 120.0 % (of rated motor voltage) 0.10 % 0.00 % STOP
S0.05 V/F frequency 3 [S0.03] ~ [b1.05] 0.01 Hz 0.00 Hz STOP
S0.06 V/F voltage 3 0.0 % ~ 120.0 % (of rated motor voltage) 0.10 % 0.00 % STOP
S0.07 ~ S0.19 Reserved
Enhanced V/F control
Code Name Setting range Min. unit Default Attri.
S0.20 Rated motor slip frequency 0.00 ~ 20.00 Hz 0.01 Hz 0.00 Hz RUN/STOP
S0.21 Voltage boost
0.1 % ~ 20.0 %: manual voltage
boost
0.0 %: automatic voltage boost
(of rated motor voltage)
0.1 % 5.0 % RUN/STOP
S0.22 I*R boost factor 0 % ~ 320 % 1 % 100 % RUN/STOP
S0.24
Heavy load voltage stabili-
zation
0: Disable; 1: Enable 1 1 RUN/STOP
S0.25 Anti hunting factor 0 % ~ 5,000 % 1 % 0 % RUN/STOP
S0.26 Anti hunting filter factor 10 % ~ 2,000 % 1 % 100 % RUN/STOP
S0.23, S0.27 ~ S0.29 Reserved
