8.4.2 Motor Physical Data
S2.10 Stator resistance
Setting range 0.00 ~ 50.00 Ω
Minimum unit 0.01 Ω
Factory default Depends on model
S2.11 Rotator resistance
Setting range 0.00 ~ 50.00 Ω
Minimum unit 0.01 Ω
Factory default Depends on model
S2.12 Leakage inductance
Setting range 0.00 ~ 200.00 mH
Minimum unit 0.01 mH
Factory default Depends on model
S2.13 Mutual inductance
Setting range 0.0 ~ 3,000.0 mH
Minimum unit 0.1 mH
Factory default Depends on model
S2.14 No-load current
Setting range 0.00 A ~ [S2.04]
Minimum unit 0.01 A
Factory default Depends on model
S2.15 Physical data calculation
Setting range 0 ~ 3
Minimum unit 1
Factory default 0
S2.16 ~ S2.19: Reserved
The motor parameters (S2.00 ~ S2.05) must be set before using "Physical data
calculation" S2.15. The necessary data can be found on the nameplate of motor.
● [S2.15] = 0: No action.
● [S2.15] = 1: Calculation. After the calculation is complete, parameters S2.10
~ S2.14 will be updated.
● [S2.15] = 2: Automatic adjustment while the motor is in static mode.
● [S2.15] = 3: Automatic adjustment while the motor is rotating.
