7.3 EFC 3600 Basic Parameters Fast Settings
Using the operating panel to set the necessary parameters based on the applica-
tion loads and specifications allows the frequency converter to start rapidly. A
basic generic parameters fast setting table is given below.
● Set [b0.02] = 4 with Func and Set keys to show group "-St-".
● For parameter attributes, see chapter 17.2.1 "Description of At-
tribute Symbols in Parameter Tables" on page 220.
Function
code
Name
Setting
range
Min.
unit
Factory
default
Attributes
b0.21 Carrier frequency 1 ~ 15 kHz 1 kHz 4 kHz Run/Stop
b1.00
First frequency setting
source
0 ~ 6 1 0 Stop
b1.02
First Run command
source
0 ~ 2 1 0 Stop
b1.05 Max. frequency 50.00 ~ 400.00 Hz 0.01 Hz 50.00 Hz Stop
b1.06 Upper frequency [b1.07] ~ [b1.05] 0.01 Hz 50.00 Hz Run/Stop
b1.07 Lower frequency 0.00 Hz ~ [b1.06] 0.01 Hz 0.00 Hz Run/Stop
b1.04 Digital set frequency [b1.07] ~ [b1.06] 0.01 Hz 50.00 Hz Run/Stop
b1.10 Direction control 0 ~ 3 1 0 Stop
b1.20 Acceleration time 1
0.1 ~ 6,000.0s
0.1s 5.0s
Run/Stop
b1.21 Deceleration time 1 0.1s 5.0s
b1.22
Acceleration/decelera-
tion curve mode
0 ~ 1 1 0 Stop
b1.30 Starting mode
0 ~ 2
1 0 Stop
b1.40 Stopping mode 1 0 Stop
S0.00 V/F curve mode 1 0 Stop
S2.00 Rated motor frequency 5.00 ~ 400.00 Hz 0.01 Hz 50.00 Hz Stop
S2.01
Rated motor rotation
speed
1 ~ 30,000 rpm 1 rpm
Depends
on model
Stop
S2.02 Rated motor power 0.1 ~ 1,000.0 kW 0.1 kW Stop
S2.03 Rated motor voltage 0 ~ 480 V 1 V Stop
S2.04 Rated motor current 0.1 ~ 1,000.0 A 0.1 A Stop
Tab. 7-2: Basic parameters fast setting
